LOGGIC

Unlock the full potential of your Woodsman Pro with our advanced LOGGIC 2 control system

All new Woodsman Pro harvesters and felling heads come bundled with the Loggic 2 control system.

To upgrade your Loggic version on an existing head, please enquire about pricing.

KEY FEATURES

Advanced mapping

Built-in PDF map viewer with GPS, stem location tracking, and customisable tools such as markers, boundaries, and geofencing. Import geographic data (.kml) from Avenza Maps, Google Earth, and other platforms.

Advanced predictive-optimiser increases productivity. Loggic can even optimise remaining stem length after a topping-saw cut!

Powerful operator reporting

Produce StanForD PRI production files and detailed PDF operator reports.

Measuring is more accurate and calibration is easier with the use of control stems. Robust diameter measuring is possible with a multitude of calibration points that smooth out variation.

Wifi connected

Connect to any network, such as Starlink, and share production files via email.

Straight-forward export feature makes downloading StanForD-based reports to a USB quick and easy. (Files are STICKS compatible).

Touchscreen control

Intuitive and easy to understand user interface.

Simple and intuitive touch-screen makes learning and operating the Loggic control system simple for any operator.

Unique operator profiles

Allows multiple operators to save and customise their preferences, streamlining machine setup.

Operator profiles allow multiple users to customise their preferences independently on a single machine.

Continuous development

Developed by Woodsman Pro for Woodsman Pro harvesters and felling heads. Compatible with all previous models.

Compatible with electronic calipers and large-end paint-marking upgrades. GPS compatible for recording stem positions when used for felling.

For more information contact us on +64 7 348 1286 or email info@ensign.co.nz

ADDITIONAL FEATURES

LOGGIC HARVESTER – Additional Features

  • Advanced predictive optimiser – Predicts the best value log to cut according to cut plan, improving overall productivity.
  • Cut to diameter – Saw automatically adjusts to cut to the required diameter without fully feeding, increasing efficiency.
  • Colour marking – Supports both SED and LED systems for marking logs with colour codes.
  • StanForD compatibility – Aligns with StanforD Classic cut plan and production file standards.
  • Hourly volume monitoring – Track production volumes on an hourly basis to assess output and productivity.
  • Accurate measurement – Easy calibration with control stems for precise measurements.
  • Knife control options – Flexibility to link control of feed wheel arms and lower knives, catering to operators familiar with other brands.
  • Soft-clamp adjustment – Customisable soft-clamp settings for different log orientations (uphill, downhill, and flat), optimising knife and feed-wheel arm pressure based on log diameter.
  • Streamlined export – Simple export of StanForD reports and maps for offline access.
  • Shock loading reduction – Uses electronic cushioning to minimise shock during feed-wheel arm movement, protecting the equipment.
  • Basic cut plan reports – Enables the generation of cut plan reports for basic operations, which can be exported.
  • Electronic calliper support – Fully compatible with electronic callipers for enhanced precision.

LOGGIC FELLING HEAD – Additional Features

  • StanForD compatibility – Aligns with StanForD2010 and StanForD Classic cut plan standards.
  • Hourly stems monitoring – Track hourly stem processing rate to assess productivity.

Engineering Services Rotorua Ltd designs and manufactures each and every Woodman Pro product.

We supply a state-of-the-art control system developed in-house which specifically suits our own equipment, your local resource, and your individual requirements.

We modify and convert machines for harvesting and processing; install, test and commission the overall package; and will train your operators to get the best results from both a productivity and safety point of view.
